RYG23 Series Nema 23 Right Angle Planetary Gearbox Gear Ratio 5:1/10:1/20:1/50:1 for Nema 23 Stepper Motor
Note:
When the rated input speed of the gearbox is 1000RPM, the noise value is <=55dB; when the rated input speed is 3000RPM, the noise value is <=65dB.
This right angle gearbox is designed for the Nema 23 Stepper Motor, where the high-speed and low-speed shafts have a 90-degree or right angle relationship. One of the main advantages of a right angle gearbox is its compact size and ability to fit into tight spaces, making it a popular choice for applications where the driving equipment needs to be close to the driven equipment, such as conveyors or other machinery.
Physical Specification | |
---|---|
Frame Size(mm) | 60 x 60 |
Shaft Type | Keyway Shaft |
Gearbox Length(mm) | 99.5 / 115.5 |
Input Shaft Diameter(mm) | 8 |
Input Shaft Length(mm) | 12-31 |
Output Shaft Diameter(mm) | 14 |
Output Shaft Length(mm) | 35 |
Suit for Motor | Nema 24 |
Gearbox Type | Right Angle Planetary Gearbox |
Gear Ratio | 5:1 / 10:1 / 20:1 / 50:1 |
Input Shaft Max. Length | 31 |
